VP4-2090 Cellular and Satellite Remote Telemetry Unit

Control Solutions' i.Report VP4-2090 Global Remote Telemetry Unit is ideal for demanding remote alarm monitoring and data logging with optional GPS tracking. It includes both cellular and satellite radios built in. The VP4-2090 includes 18 hardwire sensor inputs, of which 16 are universally configurable as analog, temperature (thermistor), or discrete/dry contact inputs. Two inputs are fixed 30V inputs for battery monitoring. High speed pulse counting is provided on 2 inputs. The VP4-2090 also includes 2 discrete outputs. The VP4-2090 includes a Modbus RTU port which may operate in master or slave mode. The VP4-2090 also includes a CAN/J1939 port for applications such as engine monitoring.

Screen shot of web portal using VP4-2090 Cellular/Satellite Remote Telemetry Unit

i.Report VP4-2090
Cellular and Satellite
Wireless Remote Monitoring
with Optional GPS Tracking

• Wireless Alarm Monitoring
• Local and Server Based Data Logging
• Soft PLC for Local Control
• 16 Analog/Universal Inputs
• 4 Discrete Outputs
• 2 Discrete/Pulse Inputs
• CAN 2.0b Port
• J1939 Engine Monitoring
• RS-485 Serial Port
• Modbus RTU Master or Slave
• USB Service Port
• 2GB Local File Storage


i.Report Model VP4-2090 Cellular/Satellite Remote Telemetry Unit

• Physical point monitoring
• User programmable alarm limits
• Flexible rule template programming
• Periodic data point reporting
• Event driven alarm reporting
• SMS, email, voice notifications
• Google Maps dynamic interface
• Geo-fencing with notification of fence broken

i.Report VP4-2090 Cellular/Satellite Remote Telemetry Unit

Order code: VP4-2090
List price - starting at: $2,175.00
Your price - starting at: $1,735.00
Log in for Wholesale

 Buy VP4-2090 Online Now!



Control Solutions’ i.Report Model VP4-2090 Cellular/Satellite Remote Telemetry Unit is ideal for demanding remote alarm monitoring and data logging with optional GPS tracking. It includes both cellular and satellite radios built in. The model VP4-2090 can operate on cellular only, satellite only, or cellular with satellite backup for mobile applications. The built-in Garmin GPS receiver provides tracking data for mobile applications.

The VP4-2090 includes 18 hardwire sensor inputs, of which 16 are universally configurable as analog, temperature (thermistor), or discrete/dry contact inputs. Two are fixed analog with 30V input range for directly monitoring batteries. The VP4-2090 also includes 2 discrete outputs for functions such as generator start on command or local alarm indicator.

The VP4-2090 includes a Modbus RTU port which may operate in master or slave mode. The VP4-2090 may poll multiple Modbus slaves to greatly expand I/O capability. The VP4-2090 may also operate as a slave allowing a PLC in a larger system to write data to the VP4-2090.

The VP4-2090 also includes a CAN/J1939 port for applications such as engine monitoring. The VP4-2090 can receive any standard J1939 message, including transport protocol. The VP4-2090 can initiate data read requests. The VP4-2090 can transmit J1939 messages sending data provided by the web portal or derived internally. The internal GPS data can be transmitted periodically in standard J1939 format. Message construction is completely configurable, and transport protocol is supported in both directions.

The VP4-2090 supports store and forward logging. Data will be reported at regular intervals via cellular when coverage is available. When a mobile unit leaves cellular coverage, the VP4-2090 will log data to its internal 2GB data flash, and upload stored data when service is found. Meanwhile, critical alarms and data points will be reported via satellite while non-critical events and log data are stored for later forwarding.

Screen shot from web portal used with VP4-2090 Cellular/Satellite Remote Telemetry Unit

The VP4-2090 is configured over the air via the LogMyData web portal. Convenient templates simplify configuration of I/O points, mapping of Modbus registers, setting of alarm limits, and assignment of notifications to users.

Screen shot from i.CanDoIt graphical programming tool used to create control programs for the VP4-2090 Cellular/Satellite Remote Telemetry Unit

i.CanDrawIt® is included at no additional cost with every i.Report from Control Solutions. i.CanDrawIt® works just like an electrical schematic CAD program, except you draw control programs that look like circuits. The resulting software will function like the circuit you draw. i.CanDrawIt® includes visual program simulation as well as visual live debugging where supported by the target device. Set breakpoints or step through the program one visual function block at a time. Update variables and I/O objects in simulation or live.



VP4-2090 Hardware Features

• Remote monitoring and data logging
• Tracks 400 data points with dual alarm thresholds per point
• Supports trending and report-on-delta for all 400 points
• Cellular and satellite connectivity options:
     • Satellite only
     • Cellular only
     • Cellular with satellite backup
• GPS tracking and geo-fencing for mobile apps
• CAN 2.0b/J1939 communication port
• Engine monitoring functions assigned to any data object
• Modbus RTU master/slave port
• 2GB data flash for event and data logging
• Battery backed real time clock for timestamps
• Programmable soft PLC included
• Over the air (GPRS/CDMA/satellite) control
• Over the air (GPRS/CDMA) firmware update
• GPRS or CDMA cellular data modem
• LEO Satellite transceiver (Iridium)
• GPS option included in some cellular modems
• 16 Universal inputs
     • 0-10VDC, thermistor, dry contact
     • 4-20mA with external resistor
     • 16-bit sigma-delta converter
     • Continuously self calibrating
• 2 Fixed analog inputs, 0-30VDC input range
• 2 Discrete outputs, 30VDC 1A open drain FET
• Internal temperature sensor
• Hardened RS-485 serial port (Modbus RTU)
• USB port (connects to laptop for service)
• 32-bit ARM7 processor, 512K Flash
• 2GB data flash for event/data logging
• 128K EEPROM for configuration storage
• Operates from 10-30VDC or 12-24VAC
• NEMA 4X, IP66, IP68 Enclosure
• Operating temperature 0°C to +70°C
• Operating range -30°C to +70°C optional

GPS Tracking Modes

Geo-fence: Reports as an alarm any time the device leaves a designated perimiter. User can reset perimeter for transportable equipment's new location.

Travel: Reports as an event every time the device moves a specifed distance, used for tracking mobile devices that are intended to be on the move.




• VP3-2290-3690 Support Package
Contains programming software, USB driver, documentation.
(Same package also supports VP4-2090.)

• Download Copy of Online Help


• Modbus Tutorial
Introduction to Modbus, including function codes, exception codes, register numbering.
