Babel Buster 4 - The Next Generation

The new Babel BusterĀ® 4 brings together all of the best features of our most popular Babel Buster 2 family gateways plus everything else you asked for along the way. By incorporating a full implementation of Linux, we leave the door wide open to adaptation to an endless array of protocols, applications, and features. Plus, programmers with PHP and Json experience can turn the user interface into anything they like.

Protocol support in initial release includes Modbus and SNMPv3, with BACnet soon to follow. There is only one model - you just keep adding protocols as they become available. There is no added charge for adding an open protocol.

Read more about Babel Buster BB4-8422

Control Solutions' New Logo

Control Solutions has a new logo that will begin appearing on new products introduced after January 1, 2018. Labels on existing products will be updated as inventories of original labels are exhausted. Literature will also be updated with the new logo as time permits.


Babel Buster Pro-V210, Featuring the Most Intelligent Connection Yet Between Modbus and SNMP

Control Solutions' Babel Buster® Pro-V210 is a an enhanced gateway with advanced features to support connecting Modbus RTU and TCP to SNMP v1 and v2c. The Pro-V210 also includes support for connecting devices having a proprietary serial protocol to SNMP or Modbus TCP.

The Pro-V210 includes an automatic table walker with multiple algorithms making it suitable for walking the sparse alarm table found in UPS systems implementing RFC 1628. The table walker can easily translate the alarm table into a series of Modbus coils for easy access by a PLC.

The Pro-V210 includes a trap receiver supporting both v1 and v2c traps. The template driven trap receiver provides multiple algorithms for recognizing traps, and can easily place trap information into holding registers for Modbus access. If more complex treatment of trap information is needed, such as character string interpretation, Script Basic can be used to process traps and place resulting data into Modbus registers.

Read more about Babel Buster Pro-V210

Babel Buster SPX Pro V2, Featuring the Most Intelligent Connection Yet Between Modbus and SNMP

Control Solutions' Babel Buster® SPX Pro V2 is the low cost version of our enhanced gateway with advanced features to support connecting Modbus RTU and TCP to SNMP v1 and v2c. The SPX Pro V2 shares all of the features of the Pro V210 in a small lower cost form factor.

The Pro V210 and SPX Pro V2 share these exciting features:
• Trap Receiver
• Trap Sender
• Automatic Table Walker
• 64-Bit Registers
• Character String Support
• Script Basic Built In

The Babel Buster Pro can receive SNMP traps and respond by sending Modbus requests to a PLC or I/O device to trigger relays in response to the SNMP trap.

The character string support in the Pro lets you easily interact with Modbus display devices. The Script Basic string handling functions let you format display messages, and also support processing messages received in traps.

Read more about Babel Buster SPX Pro V2

Babel Buster Pro-V230, Featuring the Most Intelligent Connection Yet Between BACnet and SNMP

Control Solutions' Babel Buster® Pro-V230 is a an enhanced gateway with advanced features to support connecting BACnet IP and MS/TP to SNMP v1 and v2c. The Pro-V230-SP includes support for connecting devices having a proprietary serial protocol to SNMP or BACnet IP.

The Pro-V230 includes an automatic table walker with multiple algorithms making it suitable for walking the sparse alarm table found in UPS systems implementing RFC 1628. The table walker can easily translate the alarm table into a series of Binary Input objects for easy access by a Building Management System.

The Pro-V230 includes a trap receiver supporting both v1 and v2c traps. The template driven trap receiver provides multiple algorithms for recognizing traps, and can easily place trap information into BACnet objects. If more complex treatment of trap information is needed, Script Basic can be used to process traps and place resulting data into BACnet objects. The trap receiver can convert SNMP Traps into BACnet COV notifications.

Read more about Babel Buster Pro-V230
